Cinelli Nemo Tig Gravel II gravel bike

Completely redesigned for 2024, the Nemo Gravel represents the most versatile and hybridDesigned by Cinelli to this day. Handmade by the manufacturer of Cinelli in its Milan headquarters, it uses custom triple-thick tubes designed by its sister company Columbus, less than 100 metres from the manufacturing plant.

Refined over a year of testing by riders including former UCI World Champions, legendary NYC couriers, professional snowboarders, and many other athletes pushing the boundaries of gravel riding, the Nemo Gravel is characterized above all by its completely redesigned geometry, clearance for 700 x 47 mm tires, and the use of the HiRide Sterra fork with 20 mm of true hydraulic travel.Together, these features create a bike ready to take on the most extreme gravel races and rides in the world.

New:

• New geometry completely redesigned for more extreme terrain.
• New tire clearance 700 x 47 mm thanks to a specific moulded rear base.
• Designed specifically for the HiRide Sterra fork system : 20mm of hydraulic travel optimized for gravel combined with the stiffest suspension legs on the market, requiring little maintenance and offering many other features.
• Since March 2023, all Nemo frames are manufactured at the headquarters of Cinelli milan, creating the world's shortest supply chain for high-end road bikes.
• Custom shape saddle haubans with oriented ellipses and lowered seat tube weld to optimize comfort over long distances.
• New saddle necklace.
• Tubes Columbus Spirit triple thickness custom-designed.
• Adaptive geometry with rigid fork option thanks to fork legs Columbus allowing the offset to be changed from 47 to 52 mm.
• Design-oriented details and finish.
• Available in 7 colors.
• Made to order, production time approx 1 to 2 months.

Frame specifications:

• Sizes: XS (48) - S (51) - M (54) - L (56) - XL (59) - XXL (61) / Custom made
• Material: Tubes Columbus Spirit HSS
• Steering game: IS 42/28.6 |IS 52/40
• Seat post: Ø 27.2 mm
• Seat clamp: CNC machining ø 29.8
• Bottom bracket: T47 68 mm
• Front derailleur: Collar Ø 28.6 mm
• Wiring: External/internal cable routing for hydraulic disc brake
• Colors: 6 + 1 color of the year
• Tire clearance: up to 700 x 47 mm
• Fork: Fork Hiride Sterra Columbus Disc 1-1/8
• Weight : Frame 2000 g (size M) Fork Columbus 480 g (not cut) / Sterra 1300 g
• Brake: Flat Mount disc brake, rotor size up to 160 mm (back) - 180 mm (front)
• Legs: Rear TA Ø 12x142 mm - M12x173 / Front TA Ø 12x100 mm - M12x119
• Weight : frame 2000g / fork 418g (size M 54)

Configurations (optional):

Size Guide:

FAQ:

1. The frame Cinelli Is Nemo Gravel made in Italy ?
   Yes, it is entirely made in Italy by the frame builders Cinelli using tubes Columbus.

2. How long does it take to receive my bike after ordering ?
   The Nemo Gravel is custom-made and assembled, it takes approximately 1 to 2 months To receive your bike.

3. What is the maximum tire clearance ?
   47 mm.

4. Is it possible to request a specific gallows length and width of handlebars ?
   Yes, both items can be ordered in the size of your choice: 40-42-44 cm handlebars and 70-80-90 mm stem.Send us a message to specify this when ordering.

5. Is the Nemo Gravel frame compatible with electronic groupsets (Shimano Di2 / Campagnolo EPS / SRAM EXS) ?
   Yes. Compatibility with electronic groups is considered to be a personalized change and carries an additional cost of €350, upon request.

6. Is it possible to integrate wiring on this model ?
   No, unfortunately integrated wiring is not currently possible, but Cinelli works with Columbus to propose this solution.

7. Is it possible to change the speed ratio of the Nemo Gravel ?
   No, the gear ratio of the supplied groupset cannot be changed.
